Product features |
|
|
Thickness thin, can reduce the thickness and the weight of the display, high reliability, loading ability, wide voltage input 90-264 vac, PF0.95 or higher
Double backup mode
|
|
|
Protection: overload/short circuit protection |
|
|
100% full load high temperature ageing |
|
|
2 years warranty |
|
|
Size: 130 x55x29mm |
|
|
|
|
|
|
The input voltage/frequency of input |
90~264VAC/47~63HZ |
|
The surge current |
Cold start, 40 a / 230 vac |
|
Linear regulation |
0.5% or less |
|
Output overload protection |
110% - 150% cut output, input after the restart |
|
Rise, keep time |
50 ms, 20 ms rated load |
|
Dielectric strength |
I/P-O/P£º3KVAC, I/P-FG£º1.5KVAC, O/P-FG:0.5KVAC,1min |
|
Working temperature |
- 30 ¡æ ~ + 60 ¡æ |
|
Storage temperature |
- 40 ¡æ ~ + 100 ¡æ, 20 ~ 95% RH without condensation |
|
Safety standards |
GB4943£¬UL60950-1£¬EN60950-1 |
|
EMC standard |
GB9254£¬EN55022£¬classB |
|
Cooling way |
Since the cold |
|
|
|
|
The product name |
The output voltage/current |
Voltage regulation accuracy |
Ripple noise |
The efficiency of |
|
A-200AU-5PN |
5V.0~40A |
Plus or minus 2% |
200mV |
p92% |
